-50°C～40°C Cold Storage

Living cell Refrigeration Cold Chain

-50 ° C～40 ° C wide temperature range refrigeration

The first two-stage scroll compressor in the world.

Living cell Refrigeration technology helps food quickly passing through the ice crystal formation range (-1 ° C to -5 ° C).

Less cell destruction can make sure a fresh test of food.

Hot Gas technology saves about 50% energy than the normal electric heating defrosting.

The temperature fluctuation of the hot gas defrosting is within 1 ° C, extending longer food preservation time.

Precision Temperature Controlling at ± 0.5 ° C, more precise temperature control to extend preservation time.

Model			YLSSDR018DWf	YLSSDR025DWf	YLSSDR035DWf
Cooling Storage Area		m³	8~18	10~25	14~35
Indoor Unit Model		-	YLDR6500Df	YLDR6500Df	YLDR6500Df
Main Unit Model		-	YLSSDR018Wf	YLSSDR025Wf	YLSSDR035Wf
Cooling Capacity		W	15000（600~15000）	18000（600~18000）	24000（600~24000）
Norminal Condition		℃	10℃/32℃	10℃/32℃	10℃/32℃
Store Room Temp.Range		℃	-50℃~40℃	-50℃~40℃	-50℃~40℃
Ambient Temp.Range		℃	-45℃~65℃	-45℃~65℃	-45℃~65℃
Power Supply		V/Hz	220V/50Hz	220V/50Hz	220V/50Hz
Max Input Power		W	5000（800~5000）	5500（800~5500）	6000（800~6000）
Max.Input Current		A	22.8A	25A	27.5A
Compressor		-	DC Inverter two stage scroll compressor
Refrigerant Type		-	R32	R32	R32
Refrigerant Weight		g	2.75	2.75	2.75
Main Unit Noise Level		dB（A）	68	68	68
Main Unit Flow Volume		m³/h	6500	6500	6500
Connect Pipe Size		mm	Φ9/Φ16	Φ9/Φ16	Φ9/Φ16
Throttling method		-	Electronic expansion valve
Connecting Type		-	Threaded Connection
Main Unit size		mm	1055879488	1055879488	1055879488
Main Unit Weight		kg	86	86	86
Indoor Unit Model			YLDR6500Df	YLDR6500Df	YLDR6500Df
Fan	Air Flow Volume	m³/h	6500	6500	6500m
	Power Supply	V/Hz	220V/50Hz	220V/50Hz	220V/50Hz
	Fan Input Power	W	240	240	240
Size	W	mm	1618.5	1618.5	1618.5
	D	mm	365.5	365.5	365.5
	H	mm	720	720	720
Net weight		kg	45	45	45
Pipe	Liquid Pipe	mm	Φ9	Φ9	Φ9
Pipe	Gas Pipe	mm	Φ16	Φ16	Φ16
